List Type for PVC WATERSTOP
| Product Code | SECTION, DRAWING, DESCRIPTION & SUITABILITY |
Width | Thickness | Safe Hydraulic Pressure (m=Meter |
|---|---|---|---|---|
| AR-65 |  Ribbed/Serrated Type with 1 Central Bulb For low hydro-static pressure heads used in expansion/contraction joints. |
150mm 150mm |
6mm 8 or 10mm |
25 |
| AR-66 |  Ribbed/Serrated Type with 1 Central Bulb For moderate pressure in RCC wall or slab. Wall/slap not less thicker than 150mm. used in exp/contraction joints |
150mm | 6mm | 32 |
| AR-60 |  Ribbed/Serrated Type with 1 Central Bulb For high Hydro-static Heads, in expansion / contraction Joints |
150mm 150mm 150mm |
8mm, 10mm & 8 to 11mm |
40 |
| AR-85 AR-86 |
 Ribbed / Serrated Type with 1 Central Bulb For medium pressure heads, for construction and expansion/contraction joints |
200mm 200mm |
5mm 6mm |
30 36 |
| AR-80 |  Ribbed / Serrated Type with 1 Central Bulb For high heads for construction, expansion/contraction |
200mm 200mm |
8mm 10mm |
50 50 |
| AR-95 |  Ribbed / Serrated Type with 1 Central Bulb For medium pressure heads and wall not less thicker than 230 mm for Const. & Exp/Contraction joints |
225mm 230mm |
4 to 5mm 4 to 5mm |
30 |
| AR-96 |  For medium pressure heads, for construction and expansion/contraction joints |
225mm 230mm |
6mm 6mm |
36 |
| AR-106 |  Ribbed / Serrated Type with 1 Central Bulb For medium pressure heads, for construction and expansion/contraction joints |
250mm | 6mm | 36 |
| AR-90 |  Ribbed / Serrated Type with 1 Central Bulb For high heads for construction and Expansion/contraction Joints |
225mm 230mm |
8mm 10mm 8to 11mm, 12mm |
50 |
| AR-100 |  Ribbed / Serrated Type with 1 Central Bulb For high heads for construction and Expansion/contraction Joints |
250mm | 8mm 10mm 12mm |
50 |
| ARS-96 ARS-90 |
 Multi Ribbed/Serrated Type WITHOUT Central Bulb Multi-Ribs and serration, Ideal PVC-Waterstops for CONSTRUCTION JOINTS |
230mm 230mm |
6mm 8/10mm |
36 50 |
| ARS96.5 |  Ribbed/Serrated Type WITHOUT Central Bulb Multi-Ribs and serration, Ideal PVC-Waterstops for CONSTRUCTION JOINTS |
240mm | 6mm | 36 |
| ARS-100 |  Ribbed/Serrated Type WITHOUT Central Bulb Multi-Ribs and serration, Ideal PVC-Waterstops for CONSTRUCTION JOINTS |
250mm 250mm |
8mm 10mm |
50 50 |
| AR-126 |  Ribbed/Serrated Type with 1 Central Bulb For Dams, Syphon, Aqueducts etc. |
300mm | 6mm | |
| AR-128 |  Ribbed/Serrated Type with 1 Central Bulb For Dams, Syphon, Aqueducts etc. |
300mm | 8mm | 52 |
| AR-120 |  Ribbed/Serrated Type with 1 Central Bulb For Dams, Syphon, Aqueducts etc. |
300mm | 10mm | 52 |
| AKB-95 AKB-96 AKB-106 AKB-100 |
 Surface Type with 2-Nos Kicker each side of Central Bulb( For expansion/contraction joints) |
225mm 230mm 250mm 250mm |
5 or 6mm 5 or 6mm 6mm 8 or 10mm |
25 |
| AK-95 AK-96 AK-106 AK-100 |
 Surface Type with 2-Nos Kicker each side of Centre (WITHOUT Central Bulb) For construction joints, externally placed type of PVC-Waterstop. |
225mm 230mm 250mm 250mm |
5 or 6mm 5 or 6mm 6mm 8 or 10mm |
25 |
| AKB-1063K AKB-1003K |
 Surface Type with 3-Nos Kicker each side of Centre Without Central Bulb(For expansion/contraction joints) |
260mm 260mm |
6mm 8 or 10mm |
25 |
| AKB-1063K AKB-1003K |
 Surface Type with 3-Nos Kicker each side of Central Bulb (For expansion/contraction joints.) |
260mm 260mm |
6mm 8 or 10mm |
25 |
| AK95IC |  Surface / Kicker Type with CRACK INDUCER |
260mm | 5 or 6mm | 30 |
| AD-65 AD-66 AD-60 |
 Dumb Bell Type with 1 Central Bulb For High Expansion / construction Joints and where differential settlement is expected. |
150mm 150mm 150mm |
5mm, 6mm & 10mm |
45 |
| ADWB65 ADWB66 ADWB60 |
 Dumb Bell Type Without Central Bulb For Construction joints |
150mm 150mm 150mm |
5mm, 6mm & 10mm |
45 |
| AD-70 |  Dumb Bell Type with 1 Central Bulb For High Expansion / construction Joints and where differential settlement is expected. |
180mm | 10mm | 45 |
| AD-95 AD-96 |
Dumb Bell Type with 1 Central Bulb For medium pressure heads, for expansion/contraction and settlement joints |
225mm 230mm |
5 or 6mm 5 or 6mm |
25 36 |
| ADWB95 ADWB96 |
 Dumb Bell Type Without Central Bulb For Construction joints |
225mm 230mm |
5mm 6mm |
45 |
| AD-90 |  Dumb Bell Type with 1 Central Bulb For High expansion /contraction and settlement joints |
225mm 230mm |
10mm 10mm |
45 |
| ADWB90 |  Dumb Bell Type Without Central Bulb For Construction joints |
230mm | 8 or 10mm | 45 |
| NCL |  Longitudinal Joints (For Contraction Joints) Canal Lining Strip to be use as contraction joint in cement concrete lining when concrete is in plastic condition. |
69mm
Height 45mm Width |
6mm | |
| NCT |  Transverse Joints (For Expansion Joints) Canal Lining Strip to be use as Expansion joint in cement concrete lining when concrete is in plastic condition. |
38mm
Height 45mm Width |
6mm |
